| Casing Material |
High-strength aluminum alloy |
| Slots |
1 system slot; 2 power slots; 1 data processing board slot; 0 expansion slots |
| Processor |
Intel® N2600 dual-core processor, clock speed 1.6GHz |
| Memory |
Onboard 2GB DDR2 SDRAM |
| Chipset |
Intel® NM10 |
| Storage |
240GB SSD with high-pressure self-destruct function |
| Communication Interfaces |
2 channels of 1M 1553B bus interfaces (1 in BC mode, 1 in MT mode) |
| Network Interfaces |
2 Gigabit Ethernet interfaces |
| Power Supply |
DC 28.5V |
| Cooling Design |
Fanless wall conduction cooling design |
| Debugging Interfaces |
1 VGA display interface; 1 RS232 serial port; 2 USB interfaces |
| Pre-installed System |
VXworks 6.8 system |
| Operating Temperature |
-45℃ to +60℃ |
| Total Weight |
Less than 3kg |
| Overall Dimensions |
95mm (H) × 146mm (W) × 190mm (D) |
| Color |
Black |
