| Core Performance Features |
Low ripple, low error, high conversion efficiency; hot-swappable; wide temperature range; dynamic current sharing |
| Structural Dimensions |
6U × 5HP |
| Voltage Input |
Wide voltage input supported |
| Voltage Output |
+12V/100A, +5V/30A, +3.3V/20A, +3.3VSB/5A |
| Output Accuracy & Ripple |
Output error < 5%; ripple < 500mV Pk-Pk (0 to 20MHz) |
| Output Power |
Not less than 1200W |
| Conversion Efficiency |
Not less than 90% |
| Cooling Method |
Conductive cooling |
| Protection Functions |
Dynamic current sharing; over-temperature protection; short-circuit protection; overload protection; over-voltage protection; over-current protection; input reverse polarity protection; input short-circuit protection; input over-voltage protection; input under-voltage protection |
| Structural Design |
Vibration-resistant and shock-resistant structural design |
| Hot-swappable |
Supported |
| Power Management |
IPMBUS power management; can report power board temperature, output voltage, and output current information to the main control board |
| Operating Temperature |
-40℃ to +60℃ |
| Storage Temperature |
-50℃ to +85℃ |
| Compliance Standard |
Meets GJB150.16A-2009 |
