2CZ5806 BMTI – Ultra Fast Recovery Diode, 160V 2.5A, DO-41 Package

Parameter	Specifications
Brand	MBTI
Part Number	2CZ5806 / 1N5806
Reverse Breakdown Voltage ( $B V$ )	$\geq$ 160V
Average Forward Current ( $I_{F}$ )	2.5A
Reverse Recovery Time ( $t_{rr}$ )	$\leq$ 25ns
Forward Voltage Drop ( $V_{F}$ )	$\leq$ 0.975V @ 2.5A
Package	DO-41

product detail

Item	Description
Part Number	2CZ5806
Manufacturer	BMTI (Beijing Microelectronics Technology Institute)
Package	DO-41
Product Type	Highly reliable ultra-fast recovery diode
Typical Applications	Switching power supplies, inverters, and high-frequency rectifier circuits with extremely high reliability requirements
Performance	Performance parameters fully meet or exceed the standard model 1N5806
