| Casing Material |
Aluminum-magnesium alloy |
| Display |
8.4″ TFT LCD display, resolution SVGA 800(H) × 600(V) |
| Touchscreen |
Five-wire resistive touchscreen |
| Processor |
Intel Atom® N270 ultra-low power processor, clock speed 1.6GHz |
| Chipset |
Intel 945GSE + ICH7M chipset |
| System Memory |
1GB DDRII 533MHz memory |
| Storage |
2.5-inch 320GB SATA hard drive (optional SSD) |
| Bus Interface |
1 channel 1M A/B channel 1553B bus interface; 1 channel 4M A/B channel 1553B bus interface |
| USB Interfaces |
2 USB 2.0 interfaces |
| Network Interface |
1 10/100 network interface |
| Power Supply |
AC 220V power supply |
| Status Indicator |
Power status indicator light |
| Operating Temperature |
-20℃ to +60℃ |
| Storage Temperature |
-40℃ to +75℃ |
| Physical Dimensions |
270mm (W) × 200mm (H) × 71mm (D) |
